AH-X9CCA new
1HP Single-Split Air Conditioner

Inverter compressor
R32 refrigerant
3 in 1 air filter
Golden Fin Coating

FEATURES
SPECIFICATIONS
SUPPORT

Grade 1 Energy Label
SHARP single-split air conditioners are awarded Grade 1 Energy Label

Indoor Unit Auto-Cleaning Function
One-touch activation for self-cleaning, dust removal, and sterilization. No manual disassembly required, ensuring efficient cooling and clean air.

Auto Swing Airflow
The louvers swing up and down automatically, spreading cool air throughout the room.

Inverter Compressor
The air conditioner maintains and locks the speed during operation. When the indoor temperature drops, the compressor will slow down accordingly, greatly reducing the energy required.

3 in 1 Air Filter
It can effectively capture fine dust and other harmful particles, achieve antibacterial, deodorizing, and decomposing odor effects, thereby improving indoor air quality.

Golden Fin Coating
The use of special anti-rust and anti-corrosion materials allows the air conditioner to continue to operate efficiently in a humid and acidic environment, extending its service life.

ECO Mode
Improves performance while cutting down energy use—achieving high-efficiency conservation that benefits both planet and pocket.

R32 refrigerant
R32 refrigerant has less impact on global warming than R410A refrigerant and has higher cooling efficiency. It can cool down the air conditioner quickly and create a cool and comfortable environment.

1 Year Warranty, 5 Years Inverter Warranty

SPECIFICATIONS
Type
Cooling Type
Cooling Capacity (BTU/h)
9008
Energy Efficiency Grading
Grade 1
Power Consumption (W)
2640
Airflow Volume of Indoor Unit (m3/hr)
250/ 270/ 320/ 390/ 430/ 470/ 500
Dehumidifying Capacity (L/hr)
0.8
Rated Voltage & Frequency (V / Hz)
220 / 50
Refrigerant
R32
Dimensions of Indoor Unit (W x H x D) (mm)
735*260*190
Dimensions of Outdoor Unit (W x H x D) (mm)
732*555*330
Weight of Indoor Unit (kg)
7.5
Weight of Outdoor Unit (kg)
22.5
Pipe Size - Liquid (mm)
1/4" (ø 6.35 mm)
Pipe Size - Gas (mm)
3/8" (ø 9.52 mm)
